YOKOGAWA CP471-00 Processor Module

Description:

This item can replace CP451-10

Cp471-00 processor module which is mounted on the CENTUM field control units. Two CP471 can be used in dual-redundant configuration on a duplexed field control unit.

  MODEL AND SUFFIX CODES Processor Module Description Model CP471 Processor Module

(for AFV30/AFV40/A2FV50/A2FV70)

 Suffix Codes -0 With no explosion protection

                       -1 With explosion protection

                        0 Basic type

                         1 With ISA Standard G3 option

Option Code/ERFI Enhanced RFI (Tokuchu) (*1)

 OPERATING CONDITIONS

•CP471 runs with CENTUM VP R6.05 or a later version of Control Function for Field Control Station.

• CP471 can be mounted only on the CENTUM field control units as shown below.

Field control unit

 These field control units are shipped with processor module CP461.

 Existing CP461 can be replaced with CP471.

2: For AFV30, = 0 and 1 are applicable to only AFV30-S.

 In CE Marking applicable countries or areas:

 a) Except for explosion protection purpose -

CP471-00 can be mounted on AFV30-S0. -

 CP471-01 can be mounted on AFV30-S1.

 b) For the purpose which requires an explosion protection standard.

 - CP471 cannot be mounted on AFV30-S0 and -S1.

 In the countries and areas other than CE Marking applicable countries or areas:

 a) Except for explosion protection purpose -

CP471-00 can be mounted on AFV30-S0.

- CP471-01 can be mounted on AFV30-S1.

 b) For the purpose which requires FM NI explosion protection standard.

 - CP471-10 can be mounted on AFV30-S0.

- CP471-11 can be mounted on AFV30-S1.

 AFV30-S0 and -S1 comply with only FM NI as an explosion protection standard.
