GE VOLTAGE FEEDBACK SCALING BOARD DS200NATOG3ACB
Description:
DS200NATOG3A (NATO) is a Voltage Feedback Scaling Board manufactured by GE. DS200NATOG3A is to attenuate AC and DC voltages from an SCR bridge, in ordering to accurately derived the bridge voltage feedback. DS200NATOG3A combine with two companion boards, a VME backplane, and a gate distribution and status board.

Key Features
▪ Five identical, series-connected precision resistor strings
▪ Three strings for 3-phase AC input; two strings for positive/negative DC bus voltage
▪ Configurable attenuation via 3 input stab connectors + 2 wire jumpers
▪ Integrated MOVs for overvoltage protection during output circuit interruption
▪ Single 20-pin ribbon header for all outputs (see Table 2 for pinout)

Related items:
DS200NATOG1A
DS200NATOG2A
DS200NATOG3A
