IS420UCSBS1A GE UCSB Safety Controller with 600 MHz Intel

GE IS420UCSBS1A UCSB Safety Controller with 600 MHz Intel

Brand:
General Electric PLC
Item NO.:
IS420UCSBS1A
Order(MOQ):
1 PC
Payment:
T/T
Product Origin:
USA
Shipping Port:
Xiamen
Lead Time：
In stock
Warranty:
1 year

Product Detail

IS420UCSBS1A GE UCSB Safety Controller with 600 MHz Intel
Description:
IS420UCSBS1A is one of GE Mark VieS controllers with 600 MHz Intel EP80579. IS420UCSBS1A is stand-alone computers that run the application code.
IS420UCSBS1A mounts in a panel, and communicates with the I/O packs through on-board I/O network (IONet) interfaces. IONet is a private special-purpose Ethernet that only supports Mark* controls I/O modules and controllers. IS420UCSBS1A operating system (OS) is QNX Neutrino, a real time, multitasking OS designed for high-speed, high-reliability industrial applications. Unlike traditional controllers where I/O is on a backplane, the IS420UCSBS1A does not host any application I/O. Also, all I/O networks are attached to each controller providing them with all input data. The hardware and software architecture guarantees that no single point of application input is lost if a controller is powered down for maintenance or repair.

Q&A:
1. How to install IS420UCSBS1A?
IS420UCSBS1A is contained in a single module that mounts directly to the panel sheet metal. The following diagrams display the module envelope and mounting dimensions. All dimensions are in inches. The UCSB is to be mounted to the panel as shown with vertical air flow through the fins to be unobstructed.

2. What's the Microprocessor and Memory of IS420UCSBS1A?
Microprocessor: 600 MHz Intel EP80579
Memory: 256 MB DDR2 SDRAM with error-correcting code (ECC), Flash-backed SRAM, 8K allocated as NVRAM for controller functions (Mark Vle control only), NAND flash size is 2 gigabytes.
