CA202 144-202-000-105 Industrial vibration monitoring Piezoelectric Accelerometer
Description:
CA202 144-202-000-105 Piezoelectric Accelerometer is a sensor with a piezoelectric sensing element that provides a charge output ,CA202 144-202-000-105 is Ex version with 6 meters cable.

CA202 is Industrial vibration monitoring Piezoelectric Accelerometer. The high sensitivity is 100pC/g, frequency response is 0.5 to 6000 Hz, temperature range: −55 to 260°C. CA202 is calibrated the frequency by the manufacture before shipping.

The CA202 is fitted with an integral low-noise cable that is protected by a flexible stainless-steel protection hose (leaktight) which is hermetically welded to the sensor to produce a sealed leaktight assembly.

There are different versions of CA202 can be acceptable for use in the different industrial enviornments:

• The standard verisons is for use in non-hazardous areas.
• The Ex versions is for used in potentially explosive atmospheres (hazardous areas) or harsh industrial environment.
