GE IS220PDOAH1B Discrete Output Pack
Description:
IS220PDOAH1B is Mark VIe series Discrete Output Pac. IS220PDOAH1B provides the electrical interface betwcen one or two l/O Ethernet networks and a discrete output terminal board, The l/O pack contains a BPPx processor board and an acquisition board specific to the diserete output function. IS220PDOAH1B is capable of controlling up to 12 relays and accepts terminal board specific feedback. Electromagnetic relays (with types TRLYH1B, C, D, and F terminal boards) and solid-state relays (with type TRLYH#E boards) are available.
A 3-pin input is used for exteral 28 V de power. Dual RJ-45 Ethernet connectors areprovided for an interface to the lONet, The DC-37 pin connector provides an interface tothe associated terminal board, Visual diagnostics are provided through indicator LEDs.

FAQ:
What's the difference between IS220PDOAH1B and IS220PDOAH1A?
IS220PDOAH1A contains a BPPB processor board.
IS220PDOAH1B contains a functionally compatible BPPC that is supported in the ControlST* software suite V04.04 and later.
